Galvanized Plate

Galvanized steel sheet is cut from galvanized steel coil, the base material is cold rolled steel, it has good processing performance. The zinc layer has uniform thickness, strong adhesion, no peeling during processing, and good corrosion resistance. The surface is smooth and clean, the size is accurate, the board surface is straight, the spangles are even and beautiful.

Product Detail

Product name	Galvanized plate
Standard	GB,JIS,DIN,AISI,ASTM
Grade	DX51D+Z,DX52D+Z,DC52D+Z,DC51D+Z,S350GD+Z,G550,SGCC,DD52D+Z ,SPCC,SPCD,SPCE,ST12-15,DC01-06Q195A-Q235A,Q195AF-Q235AF,Q295A(B)-Q345A(B)etc
Thickness	0.12-6.00mm
Width	600mm to 1500mm
Surface	Pre galvanized, hot dip galvanized, color coated, ect.
Zinc coating weight	60g/m2-600g/m2
Tensile strength	28.1 - 49.2kgf/mm2
Edge	Mill edge, cut edge
Delivery Time	Delivery within 7-15 days after receiving the advance payment or negotiated according to the order quantity
